The JAG RESCUE KIT is a ready-to-use reversible rescue kit designed to easily pick off and lower a victim. It contains a JAG SYSTEM haul kit, a RING OPEN gated ring, an I’D EVAC descender with integrated brake, a CONNEXION FIXE 150 cm anchor strap, a BUCKET bag and an AXIS 11 mm rope with two sewn terminations. It is available in three lengths: 30, 60 and 120 m.
Description
- Designed to easily pick off and lower a victim:- pick-off with the JAG SYSTEM haul kit, whose 4:1 mechanical advantage and excellent sheave efficiency allow the user effort to be divided by 4 when raising a victim in order to release him- evacuation with the I’D EVAC descender, whose handle is specially designed to easily lower a victim. Anti-panic function activates if the user pulls too hard on the handle, which brakes and stops the descent automatically
- Always ready to use for quick intervention:- JAG SYSTEM equipped with flexible cover that prevents any risk of tangling- rope is pre-installed in the closed brake, which is integrated in the descender to better control the descent and to provide a constant redirect- BUCKET bag for transporting the kit
– kit comes loaded and ready to use
- Available in three rope length versions: 30, 60 and 120 meters
- Rescue kit contents:- a JAG SYSTEM haul kit- a RING OPEN gated ring- an I’D EVAC descender
– an AXIS 11 mm rope with two sewn terminations
– a CONNEXION FIXE 150 cm anchor strap
– a BUCKET 25 liter bag for the 30 and 60 meter versions, and a 35 liter bag for the 120 meter version
Specifications
- Working load limit: 250 kg
- Material(s): aluminum, steel, nylon, polyurethane, polyester
References
References | K090AA00 | K090AA01 | K090AA02 |
---|---|---|---|
Length | 30 m | 60 m | 120 m |
Weight | 4300 g | 6600 g | 11300 g |
Guarantee | 3 years | 3 years | 3 years |
Packing | 1 | 1 | 1 |
